Thinkcar Thinktool Euro Master 2

Description

Thinkcar Thinktool Euro Master 2

Thinktool Euro Master 2 is a universal 10-inch diagnostic tablet equipped with a wireless VCI head compatible with the CAN FD protocol. It is a device designed for growing workshops, offering multi-brand ECU programming capabilities without the need for the PassThru protocol.

2-years of updates included in the price!



This is the latest diagnostic scanner model from THINKCAR, equipped with the newest VCI head for faster diagnostics of vehicles supporting CanFD and DoIP protocols. These are the latest standards, required by some vehicle manufacturers starting from 2022. The tester offers comprehensive diagnostic coverage of all systems installed in a vehicle, supporting over 93+ makes and models worldwide. The device is continuously updated and expanded with new features through regular online updates, increasing the potential and capabilities of the diagnostic tool.

1. OE-level diagnostics

   • Operates based on manufacturers’ service protocols.

   • Access to data and step-by-step service procedures.

2. Modularity and expansion

   • Possibility to connect additional modules: oscilloscope, ADAS, TPMS, etc.

   • Can be used as a platform for ADAS system calibration.

3. Online ECU programming

   • Supports programming and coding of ECUs for multiple brands (BMW, Mercedes, VAG, Porsche, Renault, Nissan, Hyundai, Kia, Land Rover, Jaguar, and others).

   • Also supports FCA secure gateways (Fiat, Chrysler, Alfa Romeo).

4. Service functions

   • Around 28 popular functions: DPF regeneration, AdBlue reset, injector coding, adaptations, battery registration, sensor calibration, etc.

5. Data display and tests

   • Live data in the form of tables, graphs, and waveforms.

   • Recording and comparing data in real time.

   • Active tests (actuations) and adaptations.

41 service functions:



Online Programming:

The device offers online programming functions for vehicle brands such as Audi, BMW, Land Rover, Mercedes-Benz, Nissan, Porsche, Seat, Skoda, Subaru, VW, and many others, allowing direct ECU updates and coding via the internet. The tester can program ECUs in a “virgin” state or perform updates to the latest available version.

The diagnostic tester allows unlocking SGW gateways for manufacturers:

• FCA Group (Abarth, Alfa Romeo, Chrysler, Dodge, Fiat, Fiat Professional, Jeep, Lancia, RAM i Maserati)
• Renault oraz Dacia
• Mercedes-Benz
• VAG Group (coming soon)

Device equipment:

• 10 adapters for vehicles without EOBD

Optional equipment:

• Infrared camera in the form of a module installed in the diagnostic tool housing,
• Battery tester in two versions: as a module installed in the tester or as a Bluetooth attachment – ThinkEasy,
• Four-channel oscilloscope connected via USB port,
• LED flashlight as an adapter plugged into the diagnostic tester,
• Endoscope camera connected via USB port,
• Thermal printer connected to the diagnostic tester,
• 10 adapters for vehicles without EOBD,
• IMMO support module (PROG 2),
• TPMS sensor module communicating via Bluetooth (T-Wand 200),
• Truck vehicle module – software + additional cables (HD package)

Technical specifications:

• Operating system: Android 10
• Processor: 8-core 2.0 GHz processor
• Memory: 4 GB RAM, 64 GB ROM
• Display: 10-inch touchscreen
• Rear camera: 8 megapixels
• Battery: 12,600 mAh / 3.7 V
• Network: Wi-Fi, WLAN 802.11 b/g/n
• Bluetooth: 5.0

Package contents:

• Thinkcar Thinktool Euro Master 2 diagnostic tablet

• TVCI diagnostic head

• Set of adapters for various OBD ports

• Carrying case

• Card with activation code

• Charger (EU plug)
